DPH1 (0x85) – Data Pointer-1 High Byte
Bit Name
7:0 DPH1[7:0]
DPL1 (0x84) – Data Pointer-1 Low Byte
Bit Name
7:0
DPL1[7:0]
DPS (0x92) – Data-Pointer Select
Bit Name
7:1 –
0 DPS
2.3.2 Registers R0–R7
There are four register banks (not to be confused with CODE memory space banks that only apply to flash
memory organization) of eight registers each. These register banks are mapped in the DATA memory
space at addresses 0x00–0x07, 0x08–0x0F, 0x10–0x17, and 0x18–0x1F. Each register bank contains the
eight 8-bit registers R0–R7. The register bank to be used is selected through the program status word
PSW.RS[1:0]. Register bank 0 uses flip-flops internally for storing the values (SRAM is bypassed or
unused), whereas banks 1–3 use SRAM for storage. This is done to save power. Typically, the current
consumption goes down by approximately 200 μA by using register bank 0 instead of register banks 1–3.

2.3.3 Program Status Word

The program status word (PSW) contains several bits that show the current state of the CPU. The PSW is
accessible as an SFR, and it is bit-addressable. The PSW is shown as follows and contains the carry flag,
auxiliary carry flag for BCD operations, register-select bits, overflow flag, and parity flag. Two bits in the
PSW are uncommitted and can be used as user-defined status flags.
PSW (0xD0) – Program Status Word
Bit Name
7 CY
6 AC
5 F0
4:3 RS[1:0]
2 OV
1 F1
0
P
SWRU191F – April 2009 – Revised April 2014
Submit Documentation Feedback
Reset R/W
0x00 R/W Data pointer-1, high byte
Reset R/W
0x00 R/W Data pointer-1, low byte
Reset R/W
0000 000 R0 Reserved
0 R/W Data pointer select. Selects active data pointer.
0: DPTR0
1: DPTR1
Reset R/W
0 R/W Carry flag. Set to 1 when the last arithmetic operation resulted in a carry (during
addition) or borrow (during subtraction); otherwise, cleared to 0 by all arithmetic
operations.
0 R/W Auxiliary carry flag for BCD operations. Set to 1 when the last arithmetic operation
resulted in a carry into (during addition) or borrow from (during subtraction) the high-
order nibble, otherwise cleared to 0 by all arithmetic operations.
0 R/W User-defined, bit-addressable
00 R/W Register bank select bits. Selects which set of R7–R0 registers to use from four
possible banks in DATA space.
00: Register bank 0, 0x00–0x07
01: Register bank 1, 0x08–0x0F
10: Register bank 2, 0x10–0x17
11: Register bank 3, 0x18–0x1F
0 R/W Overflow flag, set by arithmetic operations. Set to 1 when the last arithmetic
operation is a carry (addition), borrow (subtraction), or overflow (multiply or divide).
Otherwise, the bit is cleared to 0 by all arithmetic operations.
0 R/W User-defined, bit-addressable
0 R/W Parity flag, parity of accumulator set by hardware to 1 if it contains an odd number of
1s; otherwise it is cleared to 0.
Copyright © 2009–2014, Texas Instruments Incorporated
Description
Description
Description
Description
8051 CPU
CPU Registers
