Flash Write

6.2.2 Writing Multiple Times to a Word

The following rules apply when writing multiple times to a 32-bit word between erase:
• Writing 0 to a bit within a 32-bit flash word, which has been set to 1 by the last erase operation,
changes the state of the bit to 0, subject to the last bullet below.
• It is possible to write 0 to a bit within a 32-bit word repeatedly (subject to the last bullet below) once the
bit has been written with 0. This does not change the state of the bit.
• Writing 1 to a bit does not change the state of the bit, subject to the last bullet below.
• The following limitations apply to writes subsequent to the last page erase:
– A 0 must not be written more than two times to a single bit.
– A 32-bit word shall not be written more than 8 times.
– A page must not be written more than 1024 times.
The state of any bit of a 32-bit flash word is nondeterministic if these limitations are violated.
This makes it possible to write up to 4 new bits to a 32-bit word 8 times. One example write sequence to a
word is shown in Table
technique is useful to maximize the lifetime of the flash for data-logging applications.
Step Value Written
1 (page erase)
2 0xFFFFFFFb
3 0xFFFFFFb
4 0xFFFFFb
5 0xFFFFb
6 0xFFFb
7 0xFFb
8 0xFb FFFFFF
6
9 0xb FFFFFFF
7

6.2.3 DMA Flash Write

When using DMA write operations, the data to be written into flash is stored in the XDATA memory space
(RAM or registers). A DMA channel is configured to read the data to be written from the memory source
address and write this data to the flash write-data register (FWDATA) fixed destination address, with the
DMA trigger event FLASH (TRIG[4:0] = 1 0010 in DMA configuration) enabled. Thus, the flash controller
triggers a DMA transfer when the flash write-data register, FWDATA, is ready to receive new data. The
DMA channel should be configured to perform single-mode, byte-size transfers with the source address
set to start-of-data block and destination address to fixed FWDATA (note that the block size, LEN in
configuration data, must be divisible by 4; otherwise, the last word is not written to the flash). High priority
should also be ensured for the DMA channel, so it is not interrupted in the write process. If interrupted for
more than 20 μs, the write operation may time out, and the write bit, FCTL.WRITE, is set to 0.
When the DMA channel is armed, starting a flash write by setting FCTL.WRITE to 1 triggers the first DMA
transfer (DMA and flash controller handle the reset of the transfer).
Figure 6-1 shows an example of how a DMA channel is configured and how a DMA transfer is initiated to
write a block of data from a location in XDATA to flash memory.
74
Flash Controller
6-1. Here b represents the 4 new bits written to the word for each update. This
n
Table 6-1. Example Write Sequence
FLASH Contents After Writing
0xFFFFFFFF
0xFFFFFFFb
0
F 0xFFFFFFb
1
FF 0xFFFFFb
2
FFF 0xFFFFb
3
FFFF 0xFFFb
4
FFFFF 0xFFb
5
0xFb
0xb b
7
