F.5 Front Panel Operation
Note: The same version of firmware (FW/0713-34L, 4.12A) is used for the asynchronous
overhead channel unit, whether or not the AUPC option is installed. However, if the
modem hardware does not support AUPC, the AUPC-related menus and options (e.g.,
SELECT REMOTE; SELECT CONFIG, AUPC) will not be displayed in the front panel
menus.
The modem front panel control uses a tree-structured menu system (Tables F-3 through
F-12) to access and execute all functions.
The main level of the menu system is the Select menu, which may be accessed from the
base level by pressing any of the arrow keys. From the Select menu, any one of six
functional categories can be chosen:
•
•
•
•
•
•
Note: For general information on front panel operation, refer to Chapter 4.
F–12
Configuration
Monitor
Faults
Stored faults (StFaults)
Remote
Utility
