Table F-5. Select Configuration Demodulator Menu (with AUPC)

Menus
RX-x Code_Rate
RX_Freq
Dscrmblr
IFLoopBk
RFLoopBk
SWP_RACQ
SWP_CNTR
SWP_RNGE
SWP_DIR
BERT_set
F–14
Submenus/Options
x = A, B, C, D, or V
50.000 to 90.000 MHz, or
100.000 to 180.000 MHz
ON
OFF
ON
OFF
ON
OFF
0 to 999 sec
0 to 50000 Hz
-25000 to +25000 Hz
FORWARD
REVERSE
1E-3
1E-4
1E-5
1E-6
1E-7
1E-8
NONE
SDM-650B Satellite Modem
Comments
In 2.5 kHz steps.
Appear only when fast acquisition is
turned ON.
Appear only when fast acquisition is
turned ON.
Appear only when fast acquisition is
turned ON.
