F.5.2.2 Select Monitor
Refer to Table F-8.
When the Monitor level is entered, use
Each monitor function is displayed in real time as long as it is selected.
Raw_BER
Cor_BER
Eb/N0
SWP Freq
Fil_Stat
RXSignal
RX 2047
Note: When the decoder loses lock, no data is available, and is so indicated.
Rev. 5
Function
Raw bit error rate.
Range: < 1.0E-4 to 2550E-4
Corrected bit error rate.
Range: < 1.0E-8 to > 1E-3
Energy(bit)/noise ratio.
Range: < 3.2 to > 9.7 dB
Sweep monitor.
Range: -30,000 to +30,000 Hz
Plesiochronous buffer fill status in percent.
Range: 1% to 99%
Receive signal level.
Range: < -60 to -30 dBm
Receive 2047 BER.
Range: < 1.0E-3 to > 1E-6, < 1E-6, or no data
Asynchronous Overhead Channel Unit
and to select the desired monitor function.
[ ← ] [ → ]
Description
(See Note)
(See Note)
(See Note)
(See Note)
(See Note)
F–29
