Asynchronous Overhead Channel Unit
F.5.2.1.4 Configuration AUPC
Refer to Table F-7.
AUPC
NOM PWR
MIN PWR
MAX PWR
Eb/N0 SP
MAX TR
LOCAL CL
REMOTECL
F–28
Programs the AUPC ON or OFF.
On entry, the current status is displayed with the flashing cursor on the first
character. Use the arrow keys to select ON or OFF. Press [ENTER] to
execute the change.
Programs the nominal power value of the AUPC.
On entry, the current nominal power value is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The nominal power value can range from -30
to -5 dBm. Press [ENTER] to execute the change.
Programs the minimum power level of the AUPC.
On entry, the current minimum power level is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The minimum power level can range from -30
to -5 dBm. Press [ENTER] to execute the change.
Programs the maximum power level of the AUPC.
On entry, the current maximum power level is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The maximum power level can range from -
30 to -5 dBm. Press [ENTER] to execute the change.
Programs the E /N target setpoint.
b 0
On entry, the current E /N
b
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The E
to 9.7 dB, in 0.1 dB increments. Press [ENTER] to execute the change.
Programs the maximum tracking rate of the AUPC.
On entry, the current maximum tracking rate is displayed with the flashing
cursor on the first character. Use the arrow keys to increment or decrement
the digit at the flashing cursor. The maximum tracking rate can range from
0.5 to 6 dBm/minute. Press [ENTER] to execute the change.
Programs the local carrier loss for maximum, nominal, or hold.
On entry, the current status of the local carrier loss is displayed with the
flashing cursor on the first character. Use the arrow keys to select maximum,
nominal, or hold. Press [ENTER] to execute the change.
Programs the remote carrier loss for maximum, nominal, or hold.
On entry, the current status of the remote carrier loss is displayed with the
flashing cursor on the first character. Use the arrow keys to select maximum,
nominal, or hold. Press [ENTER] to execute the change.
SDM-650B Satellite Modem
target setpoint is displayed with the flashing
0
/N target setpoint can range from 3.2
b 0
