Asynchronous Overhead Channel Unit
CH LENTH
STOP BIT
PARITY

Table F-7. Select Configuration AUPC Menu (with AUPC)

Menus
AUPC
NOM PWR
MIN PWR
MAX PWR
Eb/N0 SP
MAX TR
LOCAL CL
REMOTECL
Menus
Raw_BER
Corr_BER
Eb/N0
SWP FREQ
Fil_Stat
RXSignal
RX 2047
Note: Data is not available or displayed when the decoder loses lock.
F–16
5 bits
6 bits
7 bits
8 bits
1 bit
2 bits
EVEN
ODD
NONE
Submenus/Options
ON
OFF
-30 to -5 dBm
-30 to -5 dBm
-30 to -5 dBm
3.2 to 9.7 dB, in 0.1 dB steps
0.5 to 6 dBm/minutes
MAXIMUM
NOMINAL
HOLD
MAXIMUM
NOMINAL
HOLD

Table F-8. Select Monitor Menu (with AUPC)

Submenus/Options
Range: < 1.0E-4 to 2550E-4
Range: < 1E-8 to > 1E-3
Range: < 3.2 to > 9.7 dB
Range: -30000 to +30000 Hz
Range: 1% to 99%
Range: < -60 to > -30 dBm
Range: < 1.0E-3 to > 1E-6, or No
Data
SDM-650B Satellite Modem
Comments
Comments
Displays information when fast
acquisition has been turned ON in the
Utility menu.
Rev. 5
