SDM-650B Satellite Modem
B.2.8 Status Commands/Responses
B.2.8.1 Configuration Status
B.2.8.1.1 Modulator/Coder Configuration Status
The Modulator/Coder configuration status command causes a block of data to be returned
by the addressed modem. The block of data reflects the current configuration status of the
Modulator/Coder.
Command:
Response:
Rev. 6
<add/MCS_"cr"
>add/MCS_"cr"
RF_xxx"cr"
MF_nnn.nnnn"cr"
MPO_snn.n"cr"
MOP_snn.n"cr"
MR_nnn_mmmm.m"cr"
AMRA_nnn_mmmm.m"cr"
AMRB_nnn_mmmm.m"cr"
AMRC_nnn_mmmm.m"cr"
AMRD_nnn_mmmm.m"cr"
SE_xxx"cr"
COM_xxx"cr"
DENC_xxx"cr"
TC_xxx"cr"
AMRV_nnn.mmmm.m"cr""lf"]
Remote Control Operation
RF Output (ON/OFF)
Modulator Frequency
Modulator Power Offset
Modulator Output Power
Modulator Rate
Filter "A" Assignment
Filter "B" Assignment
Filter "C" Assignment
Filter "D" Assignment
Scrambler Enable (ON/OFF)
Carrier Only Mode (ON/OFF)
Differential Encoder (ON/OFF)
Transmit Clock (INT/EXT)
Modulator Variable Rate Assignment
(Variable Rate Option Only)
B–55
