Remote Control Operation
B.2.8.20 Change Status
This command indicates that a change has or has not occurred on either the BCS_ or the
BCSF_ response since the last BCS_ or BCSF_ poll.
Command:
Response:
B.2.8.21 Equipment Type
This command returns the equipment type polled and the software version.
Command:
Response:
B.2.8.22 Bulk Consolidated Status AUPC
Command:
Response:
B–72
<add/CS_"cr"
>add/CS_x"cr""lf"]
Where: x =
"@" = no change since last CS_ poll.
"A" = BCS_ response has changed since last CS_ poll.
"B" = BCSF_ response has changed since last CS_ poll.
"C" = Both responses have changed since last CS_ poll.
<add/ET_"cr"
>add/ET_SDM650_x.xxx"cr""lf"]
Where: x.xxx = M&C firmware version.
<add/BCSA_"cr"
>add/BCSA_p1,p2,p3, . . . pn"cr""lf"]
Where: "pn" is the last parameter returned.
Parameter 1 (p1): Local AUPC enable ON/OFF.
p1 = n, where "n" is "0" to indicate OFF, or "1" to indicate ON.
Parameter 2 (p2): Nominal Power Value.
p2 = snn.n, where "snn.n" is the Nominal Power Value in dBm.
Parameter 3 (p3): Minimum Power Value.
p3 = snn.n, where "snn.n" is the Minimum Power Value in dBm.
Parameter 4 (p4): Maximum Power Value.
p4 = snn.n, where "snn.n" is the Maximum Power Value in dBm.
Parameter 5 (p5): E /N Target Set Point.
b 0
p5 = n.n, where "n.n" is the E
Parameter 6 (p6): Max. Tracking Rate.
p6 = n.n, where "n.n" is the Max. Tracking Rate in dB/Min.
Parameter 7 (p7): Local Carrier Loss.
p7 = n, where "n" is "0" to indicate HOLD, "1" to indicate NOMINAL, or "2" to indicate
MAXIMUM.
Parameter 8 (p8): Remote Carrier Loss.
p8 = n, where "n" is "0" to indicate HOLD, "1" to indicate NOMINAL, or "2" to indicate
MAXIMUM.
Parameter 9 (p9): Interface Substitution Pattern 2047 (ON/OFF).
p9 = n, where "n" is "0" to indicate OFF, or "1" to indicate ON.
/N Target Set Point in dB.
b 0
SDM-650B Satellite Modem
Rev. 6
