SDM-650B Satellite Modem
B.2.3.4 Set Modulator Output Power Level
Command:
Response:
Status Only: <add/MOP_"cr"
Response:
Notes:
1. Must be within 25.0 dB of the modulator power offset value (see MPO_) for the
2. When local AUPC enable is programmed ON, the (MOP) Modulator Output
Rev. 6
<add/MOP_snn.n"cr"
>add/MOP_snn.n"cr""lf"]
>add/MOP_snn.n"cr""lf"]
Where:
snn.n = +20.0 to -45.0, in 0.5 dB increments for 140 MHz modulator.
snn.n = +20.0 to -30.0, in 0.5 dB increments for 70 MHz modulator.
140 MHz modulator, and within 10.0 dB of the modulator power offset for the
70 MHz modulator.
Power command is not allowed; only MOP status is allowed. See "LPC_"
command.
Remote Control Operation
B–37
