Remote Control Operation
B.2.5.3 Receive Clock
Command:
Response:
Status Only: <add/RC_"cr"
Response:
B.2.5.4 External Reference Frequency
Command:
Response:
Status Only: <add/ERF_"cr"
Response:
Note: Available with buffer support hardware only.
B.2.5.5 Interface Loopback
Command:
Response:
Status Only: <add/ILB_"cr"
Response:
B.2.5.6 Baseband Loopback
Command:
Response:
Status Only: <add/BBL_"cr"
Response:
B–46
<add/RC_xxx"cr"
>add/RC_xxx"cr""lf"]
>add/RC_xxx"cr""lf"]
Where: xxx = NRM or INV.
<add/ERF_nnnnn"cr"
>add/ERF_nnnnn"cr""lf"]
>add/ERF_nnnnn"cr""lf"]
Where: nnnnn = 8 to 99992 (external reference frequency in kHz, must be a multiple of
8 kHz).
<add/ILB_xxx"cr"
>add/ILB_xxx"cr""lf"]
>add/ILB_xxx"cr""lf"]
Where: xxx = ON or OFF.
<add/BBL_xxx"cr"
>add/BBL_xxx"cr""lf"]
>add/BBL_xxx"cr""lf"]
Where: xxx = ON or OFF.
SDM-650B Satellite Modem
Rev. 6
