5. Install the replacement daughter card, and ensure both screw holes line up with
A–2
VARIABLE RATE
MODULATOR FILTER
MOUNTING
HARDWARE (2)
Figure A-1. Modulator Filter Card Change
the mounting hardware. See Figure A-1.
If the filter is installed in the wrong position, the daughter card will
be damaged.
CAUTION
SDM-650B Satellite Modem
FIXED RATE
MODULATOR FILTER
MODULATOR
Rev. 6
