Operation

4.1.4.3 Select Faults

Refer to Table 4-4.
The Faults level is accessible from the Select menu. Faults are similar to monitor
functions, they display the current fault status of the group being displayed.
Use
[ ←
•
•
•
The current fault status is displayed on line 2 of the display in real time. Fault status is
displayed as a "+" or a "-" for each parameter monitored.
•
•
To display labels for individual faults, press [ENTER]. Use
flashing cursor to the fault to be identified. The label for that fault is immediately
displayed on line 1 of the display.
[CLEAR] can be used to exit this level of operation and return to the previous level.
The following sections outline the faults monitored and displayed in each group.
4–16
and to move between the fault groups:
] [ → ]
Mod_Flts (modulator faults)
Dmd_Flts (demodulator faults)
Ceq_Flts (common equipment faults)
"+" indicates that a fault exists.
"-" indicates that no fault exists.
SDM-650B Satellite Modem
and to move the
[ ← ] [ → ]
Rev. 5
