SDM-650B Satellite Modem
B.2.8.17 Bulk Consolidated Status
This command causes bulk modem status to be returned. To reduce the length of the
response, message parameter data are returned without identifiers.
However, parameter identification can be determined by order of return. Each status
parameter is terminated with a "," (comma), except for the last parameter, which has the
standard message termination sequence ("cr""lf"]).
For standardization reasons, some parameters may not be implemented, but will retain the
terminating "," (comma). Most of the data returned is formatted the same way as the
single command status request (refer to preceding sections).
Command:
Response:
Rev. 6
<add/BCS_"cr"
>add/BCS_p1,p2,p3, . . . pn"cr""lf"]
Where: "pn" is the last parameter returned.
Parameter 1 (p1): Modulator RF output ON/OFF.
p1 = n, where "n" is "0" to indicate OFF, or "1" to indicate ON.
Parameter 2 (p2): Modulator IF frequency.
p2 = nnn.nnnn, where "nnn.nnnn" is the modulator IF frequency in MHz.
Parameter 3 (p3): Modulator output power level.
p3 = snn.n, where "snn.n" transmitter power output power level in dBm.
Parameter 4 (p4): Modulator rate currently programmed.
p4 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Parameter 5 (p5): Modulator filter A assignment.
p5 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Parameter 6 (p6): Modulator filter B assignment.
p6 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Parameter 7 (p7): Modulator filter C assignment.
p7 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Parameter 8 (p8): Modulator filter D assignment.
p8 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Parameter 9 (p9): Scrambler enable ON/OFF.
p9 = n, where "n" is "0" to indicate OFF, or "1" to indicate ON.
Parameter 10 (p10): Carrier only mode ON/OFF.
p10 = n, where "n" is "0" to indicate OFF, or "1" to indicate ON.
Parameter 11 (p11): Differential encoder enable ON/OFF.
p11 = n, where "n" is "0" to indicate OFF, or "1" to indicate ON.
Parameter 12 (p12): Demodulator IF frequency.
p12 = nnn.nnnn, where "nnn.nnnn" is the demodulator IF frequency in MHz.
Parameter 13 (p13): Demodulator rate currently programmed.
p13 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Parameter 14 (p14): Demodulator filter A assignment.
p14 = nnn_mmmm.m, where "nnn" is the code rate, and "mmmm.m" is the data rate in
kbit/s.
Remote Control Operation
B–67
