CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.1.1

(CONFIG:) Remote (Remote Control)

Remote Control: Local
Ethernet Ser+Eth
Select Local, Serial, Ethernet, or Ser+Eth using the
the following:
SELECTION ACTION
Local
Remote control is disabled. Remote monitoring is still possible.
Serial Additional submenus are displayed – RS232, RS485-2W, and RS485-4W.
Ethernet Additional submenus are displayed – Gateway, Address, MAC, and SNMP.
Enables both the Serial and Ethernet remote ports.
Ser+Eth
Note: There are no submenus for this selection. All subsequent configuration of these ports is
accomplished using the (CONFIG:) Remote: Serial or (CONFIG:) Remote: Ethernet menus.

(CONFIG: Remote) Local

When Local is selected, remote control is disabled and local control enabled.
Once ENTER is pressed, the user is returned to the CONFIG: menu.
When Remote is selected, menu operations associated with Local control are
IMPORTANT
disabled, and the user may see the following messages and prompts when
menu or command access associated with Local control is attempted:

(CONFIG: Remote) Serial

Serial CONFIG:
Interface
Select Interface or Baudrate using the
(CONFIG: Remote) Serial
M&C Bus Interface: RS232
RS485-2W
Select RS232 or RS485-2W (2-wire) or RS485-4W (4-wire) using the
press
ENTER
Serial
THIS UNIT IS CURRENTLY
IN REMOTE MODE!!
Baudrate (
RS485-4W (
.
arrow keys, then press
E)
arrow keys, then press
Interface
E)
5–8
Revision 11
MN/CDM710.IOM
ENTER
.
ENTER
arrow keys, then
. Note
