Comtech EF Data CDM-710 Installation And Operation Manual page 185

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Faults and
Status (cont.)
Firmware
N/A 1 byte
Revisions
Gigabit FEC
GFE= 2 bytes
Enable
Gigabit FEC
GFP= 6 bytes
Base Port
Description of Arguments
C= Reserved
D= ASI Port Transmit Data Loss (Interface 1)
E= Reserved
F= ASI Frame Not Synchronized (Interface 1)
G= Reserved
H= HSSI TX Clock Failure (Interface 1)
I= Reserved
J= GBEI Card Datarate > + 200 PPM
K= GBEI Card Datarate < - 200 PPM
L= GBEI No PHY Link
M= Encoder FIFO Empty
N= Encoder FIFO Full
O= ASI Tx Input Datarate Offset > +110PPM (Interface 1)
P= Reserved
Q= ASI Tx Input Datarate Offset < -110PPM (Interface 1)
R= Reserved
S= SERDES Parity Errors
c=Rx Traffic Status
0=No faults
d=New Faults
0=No new faults
1=New faults, since last check
Query only.
Query the version information of the system. Where:
i = Bulk Image number (1 or 2)
a = Firmware Image
b = Firmware Revision
c = Firmware Date
Example: FRW?1
Command or Query.
Enables the Gigabit FEC mode in the form sn, where:
s=Slot (1, 2)
n=Enable/Disable
0=Disabled
1=Enabled
Command or Query.
Gigabit FEC Base Port number in the form snnnnn, where:
s=Slot (1, 2)
n=Port Number (0 – 65535)
A–11
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
FRW? FRW?i FRW={CR}Boot:{CR}a,b,c{CR}
FRW* Bulki:{CR}a,b,c{CR}a,b,c...
FRW#
GFE= GFE?s GFE=sn
GFE#
GFE?
GFE*
GFP= GFP?s GFP=snnnnn
GFP#
GFP?
GFP*
Revision 11
