CDM-710 Broadcast Satellite Modem
Front Panel Operation

(CONFIG: Alarms) Intfc1

Intfc1 Alarms:
Select TxClk using the
Intfc1 All Faults:
Fault Mask Flt-IFOn
Select Alarm, Fault, Masked, or Flt-IFOn using the ◄ ► arrow keys. The available choices
define an Interface fault as an Alarm, as a Fault, or to completely Mask the fault. If Flt-IFOn is
selected, this allows a fault condition to perform a redundancy switch; however output power will
be left on.

5.3.2 SELECT: Monitor

Monitor: Alarms

Event-Log
Select a submenu from the Monitor: menu branch – Alarms, Rx_Stats, or Event-Log – using
the arrow keys, then press
5.3.2.1 (Monitor:) Alarms
Live Alarms: Transmit
Receive
Refer to Table 5-4 for a listing of alarms. Alarms are reported under three main categories:
•
Tx path alarms are displayed under the Transmit category;
•
Rx path alarms are displayed under the Receive category;
•
Alarms common to the Unit are available under the Unit category.
Select Transmit, Receive, or Unit using the ◄ ► arrow keys, then press

(Monitor: Alarms) Transmit

TX Traffic:
PHY Not Connected
This screen reports only if there are modulator errors; otherwise, it report "No Errors." Press
or
ENTER
NOTE: The alarm message depicted in the above example usually indicates that the Ethernet
data cable is disconnected from the modem.
TxClk
(
arrow keys, then press
Alarm
(
Rx_Stats
ENTER
Unit ( E)
GBEI Card
(E)
to return to the previous menu.
CLEAR
E)
. The following submenu displays:
ENTER
E)
.
5–39
Revision 11
MN/CDM710.IOM
.
