CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Rx Frequency
RFQ= 9 bytes
Rx Frame Size
N/A 1 byte
Rx FEC Type
N/A 1 byte
Rx Gold Code
RGS= 6 bytes
Sequence
Index
Rx Interface
RIE= 2 bytes
Enable
Description of Arguments
Command or Query.
Rx Frequency (in MHz) in the form xxxx.xxxx:
52 to 88 MHz, and 104 to 176 MHz (70/140 Modulator)
950 to 1950 MHz (L-Band Modulator)
Resolution=100Hz.
Example: RFQ=0950.0000
Query only.
Rx Frame Size Long/Short selection in the form x, where:
0=Short,
1=Long
Example: RFS =0 (which is Short Frame Size)
Note: Valid only in DVB-S2 mode. If the unit is not locked, the query returns 'x'.
Query only.
Rx FEC coding type in the form x, where:
0=Viterbi + Reed-Solomon
1=LDPC
Note: FEC is dependent on the RX Mode Type.
Example: RFT=1 (which is LDPC coding)
Command or Query.
Rx Gold Code Sequence Index:
xxxxxx = Gold Code Sequence index ( 0 to 262141 )
Example: RGS=189063
Note: Valid only in DVB-S2 mode.
Command or Query.
Interface Slot Enable/Disable in the form sx, where:
s=Defines which interface slot (1 or 2)
x=Rx Interface Status, where:
0=Disabled
1=Enabled
Example: RIE =11 (Slot 1 Rx interface enabled)
A–48
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RFQ= RFQ? RFQ=xxxx.xxxx
RFQ?
RFQ*
RFQ#
RFS? RFS? RFS =x
RFS *
RFS #
RFT? RFT? RFT=x
RFT*
RFT#
RGS= RGS? RGS=xxxxxx
RGS?
RGS*
RGS#
RIE= RIE?s RIE=sx
RIE?
RIE*
RIE#
Revision 11
