CDM-710 Broadcast Satellite Modem
CDI-70 1000 Base-T Gigabit Ethernet (GigE) Interface Module

CDI-70 GigE Interface Firmware Upgrade Procedure

10.5.1
Procedure
Step
Identify the CDI-70 firmware product required for download:
1
•
From the CDM-710 front panel: SELECT: UTIL
(Image1 or Image2)
•
From the Serial Console port: View the CDI-70 information by selecting Operations,
then selecting Maintenance/Unit Information.
•
From Telnet via the 10/100 Ethernet Traffic port: View the CDI-70 information by
selecting Operations, then selecting Maintenance/ Unit Information.
•
From HTTP Web Server Inteface via the 10/100 Ethernet Traffic port: View the CDI-70
information by selecting the MAINT tab, then selecting the Unit Info hyperlink.
Create a temporary folder (directory) on an external PC:
2
•
For Windows Explorer: Select File > New > Folder to create a new folder, then rename it from
"New Folder" to "temp" or another convenient, unused name. Assuming "temp" works, a
"c:\temp" folder should now be created.
Note: The drive letter c: is used in this example. Any valid writable drive letter can be used.
•
For Windows Command-line: Click [Start] on the Windows taskbar, then click the
"Run..." icon (or, depending on Windows OS versions prior to Windows 95, click the "MS-
DOS Prompt" icon from the Main Menu). Then, to open a Command-line window...
At the Command-line prompt (c:\>), type "mkdir temp" or "md temp" (without quotes – mkdir
and md stand for make directory). This is the same as creating a new folder using Windows
Explorer. There should now be a "c:\temp" subdirectory created (where c: is the drive letter used in
this example).
Download the correct firmware file to this temporary folder. As shown in Figure 10-3:
3
a) Go online to: www.comtechefdata.com;
b) From the Home page menu bar, click the Support tab;
c) Click the Software Downloads drop-down or hyperlink from the Support page;
d) Click the Download Flash and Software Update Files icon;
e) Click the (Select a Product Line:) Satellite Modems hyperlink provided on the Flash and
Software Update Files page;
f) Select the CDM-710 product hyperlink from the Comtech Brand column;
g) Select the desired CDI-70 firmware version hyperlink (the firmware number for the
CDM-710's CDI-70 Gigabit Ethernet Interface module is FW12547).
Extract the files to the temporary folder on the PC. A minimum of four files should be extracted:
4
•
•
•
•
To confirm that the files have been extracted to the specified temporary folder on the PC, using
Command-line, type cd c:\temp to change to the temporary directory created in Step 2, then use the
dir command to list the files extracted from the downloaded archive file.
Interfaces
For Windows 95 or Windows 98 – Type "command".
o
For any Windows OS versions later than Windows 98 – Type "cmd" or
o
"command".
Alternately, from [Start], select All Programs > Accessories > Command Prompt.
FW12547x.bin, where "x" denotes the revision letter for the bulk image file.
ReleaseNotes_FW12547_vxxx.pdf – Where "xxx" is the complete version number;
CReflashVx.zip – The archive file containing the executable used to upload firmware to the
CDI-70.
CReflash_readme_GBEI1.TXT– Installation notes for the CReflash app.
GBEI
10–7
Revision 11
MN/CDM710.IOM
Firmware Info Image#
