Select: Config - Comtech EF Data CDM-710 Installation And Operation Manual

CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.1

SELECT: Config

CONFIG: Remote Tx Rx
Int1 Int2 Ref Aux Alarms
Select a submenu from the CONFIG: menu branch using the
. The available submenus are:
ENTER
SELECTION SECT
Remote 5.3.1.1
Tx 0
Rx 5.3.1.3
Int1 5.3.1.4
5.3.1.5
Int2 5.3.1.6
Ref 5.3.1.7
Aux 5.3.1.8
Alarms 5.3.1.9
The modem may be monitored over the remote control bus at any time. When
in Local mode, however, configuration parameters may only be changed
through the front panel. Conversely, when in Remote mode, the unit may be
IMPORTANT
monitored from the front panel, but configuration parameters may only be
changed via the remote control bus.
SUBMENU DESCRIPTION
(Remote Control) Permits defining whether the unit is being controlled locally or
remotely (see IMPORTANT note).
(Transmit) Permits defining, on a parameter-by-parameter basis, the Tx configuration
of the unit. These submenu branches would be used if the user wished to change, e.g.,
just the Tx Frequency.
(Receive) Permits defining, on a parameter-by-parameter basis, the Rx configuration
of the unit. These submenu branches would be used if the user wished to change, e.g.,
just the Rx Frequency.
(Interface) Permits configuring Interfaces plugged into Slot 1 or Slot 2 at unit's rear
panel. The menus change depending on the type of interface – as of this manual
revision, ASI, HSSI, or Gigabit Ethernet (GigE) are available:
Intfc1 CDI-40 ASI Interface only.
Intfc1 CDI-60 HSSI Interface only.
Intfc2 CDI-70 Gigabit Ethernet Interface only.
(Reference) Permits selection of the internal 10MHz Reference or allows the unit to
phase lock to an External Reference of 1, 2, 5, 10, or 20 MHz.
(Auxiliary) Permits configuring the 1:1 Modem Switching parameters of the unit.
Provides Alarm action of certain parameters.
