CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Local/Remote
LRS= 1 byte
Status
Unit MAC
N/A 12 bytes
Address
Unit Alarm
MSK= 2 bytes
Mask
Number of
N/A 3 bytes
Unread stored
Events
Soft Reboot
RBT=1 1 byte
Redundancy
RED= 1 byte
State
Serial Number
N/A 9 bytes
Software
N/A 5 bytes
Revision
Description of Arguments
Command or Query.
Local/Remote status in the form x, where:
0=Local
1=Serial
2=Reserved
3=Ethernet
4=Serial+Ethernet
Example: LRS=1 (remote Serial selected)
Query only.
MAC address of the unit, reported in hexadecimal.
Example: MAC=0006B000D2A7 (The MAC address of the unit is
00:06:B0:00:D2:A7 )
Command or Query.
Alarm mask conditions, in the form ab, where:
a=Tx AIS (0 = Alarm, 1 =Fault, 2 = Masked)
b=Spare
Example: MSK = 00
Query only.
Unit returns the Number of Unread Events, which remain stored, in the form xxx.
Note: This means unread over the remote control.
Example: NUE=126
Command only.
Soft Reboot.
1= Reboot System
Command or Query.
Unit returns the redundancy state of the unit in the form x, where:
0 = Offline
1 = Online
Notes:
1. This command can be used to force the unit offline, this is done by sending
RED=0. This is only valid if redundancy mode is enabled – if redundancy is not
enabled, then RED=0 will return an error. The unit cannot be forced online.
2. If the unit is not in redundancy mode, then the unit will always be online.
Example: RED=0 (force unit offline)
Query only.
Used to query the unit 9-digit serial number. Unit returns its S/N in the form
xxxxxxxxx.
Example: SNO=176500143
Query only.
Unit returns the value of the internal software revision installed in the unit, in the
form Boot:X.X.X Bulk1:Y.Y.Y Bulk2: Z.Z.Z.
Example: SWR=Boot:1.0.3 Bulk1:1.0.1 Bulk2:1.0.0
A–14
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
LRS= LRS? LRS=x
LRS?
LRS*
LRS#
MAC? MAC? MAC=AABBCCDDEEFF
MAC*
MAC#
MSK= MSK? MSK=ab
MSK?
MSK*
MSK#
NUE? NUE? NUE=xxx
NUE*
NUE#
RBT? N/A RBT=
RBT*
RBT#
RED= RED? RED=x
RED? (See Description of
RED* Arguments)
RED#
SNO? SNO? SNO=xxxxxxxxx
SNO*
SNO#
SWR? SWR? SWR=Boot:X.X.X Bulk1:Y.Y.Y
SWR* Bulk2:Z.Z.Z
SWR#
Revision 11
