Comtech EF Data CDM-710 Installation And Operation Manual page 191

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Tx Interface
TIE= 2 bytes
Enable
Real-time Clock
TIM= 6 bytes
Time
Tx Interface
TIP= 2 bytes
Port
Tx Location of
TLP= 1 byte
the Pilot
Temperature
N/A 3 bytes
Tx Pilot On/Off
TPI= 1 byte
Description of Arguments
Command or Query.
Interface Slot Enable/Disable in the form sx, where:
s=Defines which interface slot (1 or 2)
x=Tx Interface Status, where:
0=Disabled
1=Enabled
Example: TIE =11 (Transmit interface enabled)
Command or Query.
A time as indicated from midnight, in the form hhmmss, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: TIM=231259 (23 hours:12 minutes:59 seconds)
Command or Query.
Indicates which port on the interface is to be used (ASI card only) in the form sp,
where:
s = interface slot (1 to 2)
p = interface port/channel (1 to 4)
1 = J4
2 = J5
Example: TIP=11 (Port J4 on Interface Slot 1 selected )
Command or Query.
Tx Pilot On/Off selection in the form x, where:
0=Average,
1=Peak
Example: TLP=0 (Pilot Average selected)
Note: Valid only in DVB-S2 mode.
Query only.
Unit returns the value of the internal temperature, in degrees C, the form sxxx,
where:
s=sign (+ or -)
xxx=number of degrees.
Example: TMP=+026
Command or Query.
Tx Pilot On/Off selection in the form x, where:
0=Off,
1=On
Example: TPI=0 (Pilot Off selected)
Note: Valid only in DVB-S2 mode.
A–17
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
TIE= TIE?s TIE=sx
TIE?
TIE*
TIE#
TIM= TIM? TIM=hhmmss
TIM?
TIM*
TIM#
TIP= TIP?s TIP=sp
TIP?
TIP*
TIP#
TLP= TLP? TLP=x
TLP?
TLP*
TLP#
TMP? TMP? TMP=sxxx
TMP*
TMP#
TPI= TPI? TPI=x
TPI?
TPI*
TPI#
Revision 11
