CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.4.2

(INFO:) Tx

Tx: 0140.0000
DVBS2 8P 3/4
Using the example shown, a typical transmit data info screen may be broken down as follows:
Value
Tx: 0140.0000
17.379483
DVBS2
8P
3/4
-10.0
ON
5.3.4.3

(INFO:) Rx

RX: 0140.0000 17.379483
DVBS2 QP 1/2 LF
Using the example shown, a typical receive data info screen may be broken down as follows:
Value
RX: 0140.0000
17.279483
DVBS2
8P
1/2
LF
17.379483
-10.0 ON
Description
Tx Frequency in MHz
Data rate in Mbps
Transmission mode
(Modulation:)
QP=QPSK
8P=8-PSK
16A=16-APSK
32A=32-APSK
Code Rate
Tx Power level in dBm
Tx Power: ON = On, OF = Off
Description
Rx Frequency in MHz
Data rate in Mbps
Transmission mode
(Demodulation:)
QP=QPSK
8P=8-PSK
16A=16-APSK
32A=32-APSK
Code Rate
FECFrame Type:
SF = Short Frame
LF = Long Frame
5–47
Revision 11
MN/CDM710.IOM
