CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Rx Interface
RIE= 2 bytes
Enable
Retrieve next 5
N/A 75 bytes
unread Stored
Events
Rx Pilot On/Off
N/A 1 byte
Rx Signal Level
N/A 3 bytes
Description of Arguments
Command or Query.
Interface Slot Enable/Disable in the form sx, where:
s=Defines which interface slot (1 or 2)
x=Rx Interface Status, where:
0=Disabled
1=Enabled
Example: RIE =11 (Slot 1 Rx interface enabled)
Query only.
Unit returns the oldest 5 Stored Events which have not yet been read over the
remote control in the form {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body, where Sub-body= ABCddmmyyhhmmss is as follows:
A being the fault/clear indicator.
F=Fault
C=Clear
I=Info
B being the fault type where:
1=Unit
2=Rx Traffic
3=Tx Traffic
4=Log
C is Fault Code numbers, as in FLT? or Info Code, which is:
0=Power Off
1=Power On
2=Log Cleared
3=Global Config Change
4=Redundancy Config Change
If there are less than 5 events to be retrieved, the remaining positions are
padded with zeros. If there are no new events, the response is RNE*.
Command or Query.
Rx Pilot On/Off selection in the form x, where:
0=Off,
1=On
Example: RPI=0 (Pilot Off selected)
Note: Valid only in DVB-S2 mode. This is automatically detected on demod
acquisition, but if the unit is not locked, the query returns 'x'.
Query only.
Unit returns the value of the Rx signal level, in dBm, between +3.0 and –99.0
dBm, in the form xxx where;
xxx is the Rx signal level.
Examples: RSL=+03
RSL=-41
A–30
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RIE= RIE?s RIE=sx
RIE?
RIE*
RIE#
RNE? RNE? RNE={CR}ABCddmmyyhhmm
RNE* ss{CR}ABCddmmyyhhmmss{
RNE# CR}ABCddmmyyhhmmss{CR}
ABCddmmyyhhmmss
{CR}ABCddmmyyhhmmss
RPI= RPI? RPI=x
RPI?
RPI*
RPI#
RSL? RSL? RSL=xxx
RSL*
RSL#
