CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Tx Data Invert
TDI= 2 bytes
Tx Data Rate
N/A 10 bytes
Tx Frequency
TFQ= 9 bytes
Tx Frame Size
TFS= 1 byte
Tx FEC Type
N/A 1 byte
Tx Gold Code
TGS= 6 bytes
Sequence
Index
Description of Arguments
Command or Query.
Invert Transmit Data, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Transmit Data, where:
0=Normal
1=Inverted
Note: Command valid Only with HSSI
Example: TDI = 111 (Inverted TX Data selected)
Query only.
Composite Tx Data rate, in kbps, in the form xxxxxx.xxx.
Resolution=1 bps.
Example: TDR=002047.999 (2047.999 kbps indicated)
Command or Query.
Tx Frequency (in MHz) in the form xxxx.xxxx, where:
52 to 88 MHz, and 104 to 176 MHz (70/140 Modulator)
950 to 1950 MHz (L-Band Modulator)
Resolution=100Hz.
Example: TFQ=0950.0000
Command or Query.
Tx Frame Size Long/Short selection in the form x, where:
0=Short,
1=Long
Example: TFS =0 (Short Frame Size selected)
Note: Setting only valid in DVB-S2 mode.
Query only.
Tx FEC coding type in the form x, where:
0=Viterbi + Reed-Solomon
1=LDPC
FEC is dependent on the TX Mode Type.
Example: TFT=1 (LDPC coding indicated)
Command or Query.
Tx Gold Code Sequence Index in the form xxxxxx, where:
xxxxxx = Gold Code Sequence index ( 0 to 262141 )
Example: TGS=189063
Note: Valid only in DVB-S2 mode.
A–16
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
TDI = TDI?sc TDI =sx
TDI? (See Description of
TDI * Arguments)
TDI #
TDR? TDR? TDR=xxxxxx.xxx
TDR*
TDR#
TFQ= TFQ? TFQ=xxxx.xxxx
TFQ?
TFQ*
TFQ#
TFS = TFS? TFS =x
TFS?
TFS *
TFS #
TFT? TFT? TFT=x
TFT*
TFT#
TGS= TGS? TGS=xxxxxx
TGS?
TGS*
TGS#
