Comtech EF Data CDM-710 Installation And Operation Manual page 199

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Firmware
N/A 1 byte
Revisions
Gigabit Egress
GEF= 2 bytes
FEC Enable
Gigabit Egress
GEG= 16 bytes
Multicast Group
Address
Description of Arguments
G=ASI Rx PLL Empty (Interface 1)
H=ASI Rx PLL Full (Interface 1)
I=ASI Rx PLL Lower Limit Reached (Interface 1)
J=ASI Rx PLL Upper Limit Reached (Interface 1)
K=Reserved
L=Reserved
M=Reserved
N=Reserved
O=Reserved
P=ASI Rx SERDES Error (Interface 1)
Q=ASI Rx SERDES DCM Unlocked (Interface 1)
R= Reserved
S= Reserved
T=HSSI Rx Buffer Underrun (Interface 1)
U=HSSI Rx Buffer Overflow (Interface 1)
V=Reserved
W=Reserved
X=Framer SERDES Rx Fault (Interface 1)
Y=Framer SERDES Rx Fault (Interface 2)
Z=Reserved
[=Reserved
d=New Faults
0=No new faults
1=New faults since last check
Query only.
Query the version information of the system, where:
i = Bulk Image number (1 or 2)
a = Firmware Image
b = Firmware Revision
c = Firmware Date
Example: FRW?1
Command or Query.
Gigabit Egress FEC Enable/Disable in the form sn, where:
s=Slot (1, 2)
n=Enable / Disable, where
0 = Disabled
1 = Enabled
Command or Query.
Gigabit Egress Multicast Group Address. The multicast stream egressing from
the gigabit interface will have this IP address as the source IP address in the
form siii.iii.iii.iii, where:
s=Slot (1, 2)
i=IP Address
A–25
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
FRW? FRW?i FRW={CR}Boot:{CR}a,b,c{CR}
FRW* Bulki:{CR}a,b,c{CR}a,b,c...
FRW#
GEF= GEF?s GEF=sn
GEF#
GEF?
GEF*
GEG= GEG?s GEG=siii.iii.iii.iii
GEG#
GEG?
GEG*
Revision 11
