CDM-710 Broadcast Satellite Modem
Front Panel Operation
Media packets will be addressed to this UDP port; FEC packets (if FEC generation is
enabled) will be addressed to (UDP destination port +2).

(CONFIG: Intfc2 Gigabit Ethernet) Man

Intfc2 Management IP
192.168.001.008/24
To enter the management IP address/subnet mask for Gigabit Ethernet Interface management
channel, first use the ◄ ► arrow keys to select the desired digit to edit, then use the ▲ ▼ arrow
keys to change the value of that digit. Press

(CONFIG: Intfc2 Gigabit Ethernet) Stats

Intfc2 Statistics
View Clear
Select View or Clear using the ◄ ► arrow keys, then press
(CONFIG: Intfc2 Gigabit Ethernet) Stats
FPGA Packets Dropped
00000000000000000000
Table 5-3 lists the viewable statistics for this interface. Use the ▲ ▼ arrow keys to page
through the available statistics reports. Press

Table 5-3. Statistics for the Gigabit Ethernet Interface

Category Message
1000Base-T Link
LAN Good Octets (In)
Statistics
LAN Bad Octets (In)
LAN Unicast (In)
LAN Broadcast (In)
LAN Multicast (In)
LAN Pause (In)
LAN Undersize (In)
LAN Fragments (In)
LAN Oversize (In)
LAN Jabber (In)
LAN Rx Err (In)
LAN FCS Err (In)
LAN Octets (Out)
LAN Unicast (Out)
LAN Broadcast (Out)
LAN Multicast (Out)
ENTER
( )
ENTER
GBEI Statistics Summary
The sum of lengths of all good Ethernet frames received from the LAN.
The sum of lengths of all bad Ethernet frames received from the LAN.
The sum of good frames received from the LAN that have a unicast destination MAC address.
The sum of good frames received from the LAN that have a broadcast destination MAC address.
The sum of good frames received from the LAN that have a multicast destination MAC address.
The number of good flow control frames received from the LAN.
Total frames received from the LAN with a length of less than 64 octets but with a valid FCS.
Total frames received from the LAN with a length of less than 64 octets and an invalid FCS.
Total frames received from the LAN with a length greater than the maximum size of octets but with a
valid FCS.
Total frames received from the LAN with a length greater than the maximum size of octets but with an
invalid FCS.
Total frames received from the LAN for which an error was detected at the PHY.
Total frames received from the LAN with a CRC error that was not counted in the Fragments or Rx Err
totals.
The sum of the lengths of all Ethernet frames transmitted to the LAN.
The sum of frames transmitted to the LAN that have a unicast destination MAC address.
The sum of frames transmitted to the LAN that have a broadcast destination MAC address.
The sum of frames transmitted to the LAN that have a multicast destination MAC address.
5–35
when done.
.
ENTER
View
or when done.
CLEAR
Description
