CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Gigabit Egress
GEP= 11 bytes
Port Numbers
Gigabit Egress
GFM= 6 bytes
FEC Matrix
Gigabit
GIP= 19 bytes
Management IP
Address and
Subnet
Initialize Events
IEP= None
Pointer
Boot Image
IMG= 1 byte
IP Address
IPA= 18 bytes
Gateway
IPG= 15 bytes
Address
Description of Arguments
Command or Query.
Gigabit Egress Port Numbers in the form snnnnnppppp, where:
s=Slot (1, 2)
nnnnn = Source Port Number (0 – 65535)
ppppp = Destination Port Number (0 – 65535)
Note: Both Source Port and Destination Port must be valid for set command to
take effect.
Command or Query.
Gigabit Egress FEC Matrix in the form sll,dd where:
s=Slot (1, 2)
ll = Length, two digit number (leading zero) between 1 and 20.
dd = Depth, two digit number (leading zero) between 4 and 20.
Note: Length x Depth, must be less than or equal to 100)
Command or Query.
Gigabit Management IP address and subnet mask in the form siii.iii.iii.iii.nn,
where:
s=Slot (1, 2)
i=IP Address
n=Netmask
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the
stored events log.
Command only.
Boot image selection, where n is the image number in the form n, where:
1=Image #1
2=Image #2
Example: IMG=1 (Image #1 selected for booting.)
Command or Query.
Used to set the IP address and network prefix for the 10/100 BaseTx Ethernet
management port, in the form xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address
yy is the network prefix (00..31)
Example: IPA=010.006.030.001.24
Command or Query.
Used to set the Gateway IP addess for the 10/100 Base Tx Ethernet
management port, in the form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: IPG = 010.006.030.001
A–26
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
GEP= GEP?s GEP=snnnnnppppp
GEP#
GEP?
GEP*
GFM= GFM?s GFM=sll,dd
GFM #
GFM?
GFM*
GIP= GIP?s GIP=siii.iii.iii.iii.nn
GIP#
GIP?
GIP*
IEP= N/A N/A
IEP?
IEP*
IEP#
IMG= IMG? IMG=n
IMG?
IMG*
IMG#
IPA= IPA? IPA= xxx.xxx.xxx.xxx.yy
IPA?
IPA*
IPA#
IPG= IPG? IPG = xxx.xxx.xxx.xxx
IPG?
IPG*
IPG#
Revision 11
