CDM-710 Broadcast Satellite Modem
Ethernet Management
6.5

Web Server (HTTP) Interface

This section describes the functionality of the CDM-710 Broadcast Satellite Modem Web
Server (HTTP) Interface. Please refer to Chapter 5. FRONT PANEL OPERATION, and the
Remote Commands Specifications tables found in Appendix A. REMOTE CONTROL for
detailed descriptions of the configuration parameters featured on the individual Web pages
shown in this chapter.

6.5.1 Web Server Interface Introduction

The embedded Web Server application provides the user with an easy to use interface to
configure and monitor all aspects of the CDM-710. These Web pages have been designed for
optimal performance when using Microsoft's Internet Explorer Version 5.5 or higher (the
examples shown use Internet Explorer Version 6.0).
The user can fully control and monitor base operations of
the CDM-710 from the Web Server Interface. By rolling
the cursor over the navigation tabs located at the top of
each page (right), the user can select from the available
nested hyperlinks.

6.5.2 User Login

To initiate a Web session with the CDM-710 Broadcast Satellite Modem, from the PC type
http://www.xxx.yyy.zzzz (where "www.xxx.yyy.zzz" represents the IP address of the CDM-710) into
the Address area of the Web browser:
The Login window will appear, and the user is prompted to type a
User Name and Password.
CDM-710 Satellite Modem Web Server Default
Name/Passwords are:
Admin
Read/Write
Read Only
User Interface
Web
Type the User Name and Password, then click [OK].
comtech/comtech
opcenter/1234
monitor/1234
Admin User Read/Write User
No Access to Admin or
Encryption Web pages
Full Access to all
Web Pages
Full Access for all other Web
Pages
User Login Access Level
No Access to Admin or Encryption Web
pages
View Only Access for all other Web Pages
6–8
Revision 11
MN/CDM710.IOM
Read Only User
