CDM-710 Broadcast Satellite Modem
Front Panel Operation
(CONFIG: Intfc2 Gigabit Ethernet) Egress
Intfc2 Egress FEC Matrix:
Length = 10,
To configure the dimension of the egress FEC matrix, first use the ◄ ► arrow keys to
select the desired digit to edit, then use the ▲ ▼ arrow keys to change the value of that
digit. Press
Valid values for Length and Depth are as follows:
(CONFIG: Intfc2 Gigabit Ethernet) Egress
Intfc2 Egress IP:
Group SrcPort DestPort
To allow configuration of IP header fields for the egress packets, select Group, ScrPort, or
DestPort using the ◄ ► arrow keys, then press
(CONFIG: Intfc2 Gigabit Ethernet) Egress
Intfc2 Egress Multicast:
239.010.010.010
To enter a valid destination IP Multicast Group Address for egress IP packets, first use
the ◄ ► arrow keys to select the desired digit to edit, then use the ▲ ▼ arrow keys to
change the value of that digit. Press
(CONFIG: Intfc2 Gigabit Ethernet) Egress
Intfc2 Egress Src Port:
01024
To enter a valid UDP Source Port Address for the network, first use the ◄ ► arrow keys
to select the desired digit to edit, then use the ▲ ▼ arrow keys to change the value of
that digit. Press
(CONFIG: Intfc2 Gigabit Ethernet) Egress
Intfc2 Egress Multicast:
01024
To enter a valid UDP Destination Port Address for the egress packet stream, first use the
◄ ► arrow keys to select the desired digit to edit, then use the ▲ ▼ arrow keys to
change the value of that digit. Press
Depth = 10
when done.
ENTER
•
L * D ≤ 100
•
1 ≤ L ≤ 20
•
4 ≤ D ≤ 20
(
(
when done.
ENTER
(
5–34
FEC
IP
.
ENTER
IP
)
when done.
ENTER
IP
)
IP
)
when done.
ENTER
Revision 11
MN/CDM710.IOM
Matrix
Group
SrcPort
DestPort
