Comtech EF Data CDM-710 Installation And Operation Manual page 227

CDM-710 Broadcast Satellite Modem
Appendix A
[Tx Block] consists of 50 bytes for Transmit configuration, in the form aaaa.aaaabcc.ccccccdefghhh.hijklmmmmmmnoxxxxxxxxxx where:
aaaa.aaaa = Tx Frequency (in MHz)
b = Tx Mode
cc.cccccc = Tx Symbol Rate
d = Tx FEC Type
e = Tx Modulation type
f = Tx FEC Rate
g = Tx Spectrum Inversion
hhh.h = Tx Power Level
i = Tx Carrier State
j = Tx Alpha Roll-off
k = Tx Frame Size
l = Tx Pilots
mmmmmm = Tx Gold Code Sequence
n = Tx Location of Pilot
o = Tx Transport Stream
xxxxxxxxxx = Spare bytes.
[Rx Block] consists of 50 bytes for Receive configuration, in the form aaaa.aaaabcc.ccccccdefggghijkllllllmm.mnxxxxxxxxxx where:
aaaa.aaaa = Rx Frequency (in MHz)
b = Rx Mode
cc.cccccc = Rx Symbol Rate
d = Rx FEC Type
e = Rx Modulation Type
f = Rx FEC Rate
ggg = Rx Sweep Width
h = Rx Adaptive Equalizer
i = Rx Alpha Roll-off
j = Rx Frame Size
k = Rx Pilots
llllll = Rx Gold Code Sequence
mm.m = Rx EbNo Alarm Point
n = Rx Transport Stream
xxxxxxxxxx = Spare bytes.
same as TFQ
same as TMM
same as TSR
same as TFT (read-only)
same as TMD
same as TCR
same as TSI
same as TPL
same as TXO
same as TAR
same as TFS
same as TPI
same as TGS
same as TLP
same as TTM (in DVB-S2 & HSSI mode)
same as RFQ
same as RMM
same as RSR
same as RFT (read-only)
same as RMD (read-only in DVB-S2 mode)
same as RCR (read-only in DVB-S2 mode)
same as RSW
same as AEQ
same as RAR
same as RFS (read-only)
same as RPI (read-only)
same as RGS
same as EBA
same as RTM (read-only in DVB-S2 & HSSI mode)
A–53
Revision 11
MN/CDM710.IOM
