Comtech EF Data CDM-710 Installation And Operation Manual page 217

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Firmware
N/A 1 byte
Revisions
Gigabit Egress
GEF= 2 bytes
FEC Enable
Gigabit Egress
GEG= 16 bytes
Multicast Group
Address
Gigabit Egress
GEP= 11 bytes
Port Numbers
Gigabit Egress
GFM= 6 bytes
FEC Matrix
Gigabit FEC
GFP= 6 bytes
Base Port
Gigabit
GIP= 19 bytes
Management IP
Address and
Subnet
Description of Arguments
Query only.
Query the version information of the system, where:
i = Bulk Image number (1 or 2)
a = Firmware Image
b = Firmware Revision
c = Firmware Date
Example: FRW?1
Command or Query.
Gigabit Egress FEC Enable/Disable in the form sn, where:
s=Slot (1, 2)
n=Enable / Disable, where
0 = Disabled
1 = Enabled
Command or Query.
Gigabit Egress Multicast Group Address. The multicast stream egressing from
the gigabit interface will have this IP address as the source IP address in the
form siii.iii.iii.iii, where:
s=Slot (1, 2)
i=IP Address
Command or Query.
Gigabit Egress Port Numbers in the form snnnnnppppp, where:
s=Slot (1, 2)
nnnnn = Source Port Number (0 – 65535)
ppppp = Destination Port Number (0 – 65535)
Note: Both Source Port and Destination Port must be valid for set command to
take effect.
Command or Query.
Gigabit Egress FEC Matrix in the form sll,dd where:
s=Slot (1, 2)
ll = Length, two digit number (leading zero) between 1 and 20.
dd = Depth, two digit number (leading zero) between 4 and 20.
Note: Length x Depth, must be less than or equal to 100)
Command or Query.
Gigabit FEC Base Port number in the form snnnnn, where:
s=Slot (1, 2)
n=Port Number (0 – 65535)
Command or Query.
Gigabit Management IP address and subnet mask in the form siii.iii.iii.iii.nn,
where:
s=Slot (1, 2)
i=IP Address
n=Netmask
A–43
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
FRW? FRW?i FRW={CR}Boot:{CR}a,b,c{CR}
FRW* Bulki:{CR}a,b,c{CR}a,b,c...
FRW#
GEF= GEF?s GEF=sn
GEF#
GEF?
GEF*
GEG= GEG?s GEG=siii.iii.iii.iii
GEG#
GEG?
GEG*
GEP= GEP?s GEP=snnnnnppppp
GEP#
GEP?
GEP*
GFM= GFM?s GFM=sll,dd
GFM #
GFM?
GFM*
GFP= GFP?s GFP=snnnnn
GFP#
GFP?
GFP*
GIP= GIP?s GIP=siii.iii.iii.iii.nn
GIP#
GIP?
GIP*
Revision 11
