Using Fast Demo Mode - Comtech EF Data CDM-710 Installation And Operation Manual

CDM-710 Broadcast Satellite Modem
FAST Activation Procedure
f) If, on the other hand, the FAST code is not valid, the code is rejected and following
message is displayed:
g) Press [ENTER] or [CLEAR] as directed, then re-enter the FAST code. Contact Comtech
EF Data Customer Support if the problem persists.
C.3

Using FAST Demo Mode

When enabled, Demo Mode allows access to ALL CDM-710 FAST options for 604800 seconds (7
full days). Demo Mode may be turned on and off an unlimited number of times until the 604800
seconds have expired. The decrement countdown to zero seconds occurs only when the mode is On.
FAST Demo Mode may be enabled or disabled as follows:
a) Press [CLEAR] to return to the FAST menu:
b) Select Cnfg, then press [ENTER]:
c) Use the
d) Use the ◄ ► arrow keys to select Off or On. When On, the second line will display the
under of seconds remaining available for the free Demo Mode.
IMPORTANT
When the Demo period expires, the following menu is displayed:
FAST Code Rejected!
(ENTER or CLEAR)
FAST: Cnfg View
MainBoard S/N: 333333333
FAST Configuration:
Edit Code Demo Mode
◄ ►
arrow keys to select Demo Mode, then press [ENTER].
FAST Demo Mode: Off
604800 seconds remain
IF THE DEMO MODE STATE (OFF/ON) IS CHANGED, OR IF DEMO
MODE IS ENABLED AND THE TIMER EXPIRES, THE MODEM
FIRMWARE WILL AUTO-REBOOT AFTER 5 SECONDS.
NOTE THAT VALIDATION OF AUTHORIZED FAST OPTIONS OCCURS
ON AUTO-REBOOT; IF AN INVALID CONFIGURATION IS FOUND, THE
MODEM CONFIGURATION WILL RESET TO DEFAULT VALUES.
FAST Demo Mode: Off
Demo Period Expired
On
On
C–4
Revision 11
MN/CDM710G.IOM
