Comtech EF Data CDM-710 Installation And Operation Manual page 192

CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Tx Power Level
TPL= 5 bytes
Test Pattern
TPT= 1 byte
Transmit &
TRC= 69 bytes
Receive
Configuration
Description of Arguments
Command or Query.
Tx Output power level in the form sxx.x, where:
s=sign ( + / - )
xx.x = Tx Output power level, +05.0 and –20.0 dBm.
L-Band: -25.0 to –05.0 dBm
70/140 MHz: -20.0 to +00.0 dBm
Note: Beyond –20 dBm is beyond the specification.
Example: TPL = -13.4
Command or Query.
Set Test Pattern in the form x, where:
0=Off
1=2047
2=2^23-1
Example: TPT=1 (2047)
Command or Query.
Global configuration, in the form:
aaa.aaaabcc.ccccccdefghhhhhhiii.ijkllll.llllmnn.nnnnnnopqrsssssstuvv, where:
aaaa.aaaa = Tx Frequency (in MHz)
b = Tx Mode
cc.cccccc = Tx Symbol Rate
d = Tx FEC Type
e = Tx Modulation type
f = Tx FEC Rate
g = Tx Spectrum Inversion
hhhhhh = Tx Gold Code Sequence
iii.i = Tx Power Level
j = Tx Carrier State
k = Tx Alpha Roll-off
llll.llll = Rx Frequency (in MHz)
m = Rx Mode
nn.nnnnnn = Rx Symbol Rate
o = Rx FEC Type
p = Rx Modulation type
q = Rx FEC Rate
x = spare
ssssss = Rx Gold Code Sequence
t = Rx Alpha Roll-off
u = Unit test Mode
vv = Unit Alarm Mask
same as TFQ
same as TMM
same as TSR
same as TFT **
same as TMD
same as TCR
same as TSI
same as TGS
same as TPL
same as TXO
same as TAR
same as RFQ
same as RMM
same as RSR
same as RFT **
same as RMD
same as RCR
same as RGS
same as RAR
same as TST**
same as MSK
** Read-only
A–18
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
TPL= TPL? TPL=sxx.x
TPL?
TPL*
TPL#
TPT= TPT? TPT=x
TPT?
TPT *
TPT #
TRC= TRC? TRC=
TRC? aaaa.aaaabcc.ccccccdefghhh
TRC* hhhiii.ijkllll.llllmnn.nnnnnnopqx
TRC# sssssstuvv
Returns current transmit and
receive configuration.
Notes:
1. Unit returns 'x's for Rx
parameters if unit is modulator
only.
2. Unit returns 'x's for Tx
parameters if unit is
demodulator only.
3. If Rx is in DVB-S2 mode, the
Rx Modulation Type and Rx
FEC Rate is ignored
because these are
automatically detected.
Revision 11
