CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.2.3

(Monitor:) Event-Log

Stored Events: View
Clear-All
Refer to Table 5-4 for the listing of available alarms. Select View or Clear-All using the ◄ ►
arrow keys, then press
(Monitor:) Event-Log
Log015 23/05/06
Fault – No PHY Link
•
This window displays up to 253 Alarms.
•
Refer to Table 5-4 for the listing of available alarms.
•
Use the
•
The Event-Log stores the live alarms, along with a timestamp for review and
troubleshooting. The date is in international format: dd/mm/yy

(Monitor: Event-Log) Clear-All

Clear All Stored Events:
No Yes
Use the ◄ ► arrow keys to select No to retain, or Yes to clear the buffer of all stored events,
then press
ENTER
5.3.3

SELECT: Test

Test:
Mode TestPatterns
Test options for the Tx carrier and patterns are selected in this menu. Select a submenu from the
Test: menu branch – Mode or TestPatterns – using the ◄ ► arrow keys, then press
5.3.3.1

(Test:) Mode

Test: Normal
Tx-CW Tx-1,0
The CDM-710 supports many useful test modes. Not all modes are available in all configurations –
they depend upon the modem configuration (Duplex, Rx-Only, Tx-Only) and the data interface(s).
Select Norm, IF (Loop), I/O (Loop), RF (Loop), Tx-CW or Tx-1,0 using the ◄ ► arrow keys,
then press
ENTER
( E)
.
ENTER
View
09:27:15
(
arrow keys to display individual alarms.
( E)
.
(
RF IF I/O
( E)
.
)
E)
5–43
Revision 11
MN/CDM710.IOM
.
