CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Rx Buffer Size
RBS= 5 bytes
Soft Reboot
RBT=1 1 byte
Rx Clock
RCI= 2 bytes
Invert
Rx Clock
RCK= 2 bytes
Source
Rx Data Invert
RDI= 2 bytes
Rx Data Rate
N/A 10 bytes
Description of Arguments
Command or Query.
Rx Buffer Size (in milliseconds) in the form sxx.x, where:
s=Defines which interface slot ( 1 or 2 )
xx.x= Rx Buffer Size,
HSSI = 5.0 to 32.0 ms, in 0.1 ms steps
GBEI = N/A
ASI = N/A
Example: RBS=130.0 (selects 30.0 ms on interface 1)
Command only.
Soft Reboot.
1= Reboot System
Command or Query.
Invert Receive Clock in the form sx, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Receive Clock, where:
0=Normal
1=Inverted
Note: Command valid Only with HSSI
Example: RCI = 11 (Inverted RX Clock, Slot 1 selected)
Command or Query.
Rx Clock Source (for data rate accuracy) in the form sx, where:
s=Defines which interface slot ( 1 or 2 )
x=Rx Clock Source, where:
0=Rx Satellite
1=Tx-Terrestrial
2=External Reference Clock
3=Internal (HSSI Only)
Example: RCK=11 (Tx-Terrestrial selected)
Command or Query.
Invert Receive Data in the form sx, where:
s=Defines which interface slot ( 1 or 2 )
x=Invert Receive Data, where:
0=Normal
1=Inverted
Note: Command valid Only with HSSI.
Example: RDI = 11 (Inverted RX Data selected)
Query only.
Composite Rx Data rate, in kbps, in the form xxxxxx.xxx.
Resolution=1 bps.
Example: RDR=002047.999 (2047.999 kbps specified)
A–28
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RBS= RBS?s RBS=sxx.x
RBS? (See Description of
RBS* Arguments)
RBS#
RBT? N/A RBT=
RBT*
RBT#
RCI = RCI?s RCI =sx
RCI? (See Description of
RCI * Arguments)
RCI #
RCK= RCK?s RCK=sx
RCK? (See Description of
RCK* Arguments)
RCK#
RDI = RDI?sc RDI =sx
RDI? (See Description of
RDI* Arguments)
RDI#
RDR? RDR? RDR=xxxxxx.xxx
RDR*
RDR#
Revision 11
