CDM-710 Broadcast Satellite Modem
Front Panel Operation

(CONFIG: Aux) Ena/Dis

Redundancy Mode:
Enable
Select Enable or Disable using the ◄ ► arrow keys, then press
indicates the currently active choice. Select Enable to set up the unit for operation with the 1:1 IF
switch. Internally, an auxiliary relay sets the alarms connector for the 1:1 operation mode.
Note: Disable is selectable only when the unit is in Local mode. When the unit is in Remote
mode and the user attempts to select Disable using the ◄ ► arrow keys, the following message
is displayed:
THIS UNIT IS CURRENTLY
IN REMOTE MODE!!
Note: When redundancy is selected, J5 becomes the default port – J4 is not available for 1:1
operation. Either J4 or J5 is available for 1:N operation.

(CONFIG: Aux) FORCE(1:1)

Press ENT To Force Modem
To Standby
The Force (1:1) selection is only available for use with a 1:1 switch to force switchover, and only
from the modem that is currently online. The modem that is online is indicated by the ONLINE
LED on the modem's front panel. As prompted by the display, press
switchover; otherwise, press
5.3.1.9

(CONFIG:) Alarms

Alarm Mask: Tx
Intfc1 Intfc2
If the unit is in Local mode, select Tx, Intfc1, or Intfc2 using the
.
ENTER
However, if the unit is in Remote mode and the user attempts to select an alarm state, the
following message displays:
THIS UNIT IS CURRENTLY
IN REMOTE MODE!!

(CONFIG: Alarms) Tx

Tx Alarm Mask: None
Currently, masking of Tx Alarms (as associated with the modulator) is not allowed.
Disable (
(1:1 Only)
to return to the previous menu.
CLEAR
(
E)
E)
5–38
Revision 11
MN/CDM710.IOM
. The solid cursor
ENTER
to initiate
ENTER
arrow keys, then press
