Table 3-1. Modem Rear Panel Connectors - Comtech EF Data CDM-710 Installation And Operation Manual

CDM-710 Broadcast Satellite Modem
Rear Panel Connectors and Pinouts
Connector Group Ref Des / Name
J1 Tx
IF
Sect. 3.2
J3 Rx
J4 Ethernet
J6 SerDes
Terrestrial Data
(Initially-released chassis only
Sect. 3.3
J6 Async Channel (non-operational)
(Rev A and later chassis only
P1 Alarms
P2 Remote
Utility
J7 Ext Ref
Sect. 3.4
(Initially-released chassis only
J7 Ext Ref
(Rev A and later chassis only
AC
Power/Ground
DC (Optional)
Sect. 3.5
Ground
Notes:
1. The initially released chassis is Tx only and does not support 1:1 operation. It does not support
1:N operation and is not upgradeable. This chassis is also not upgradeable to Rx only or duplex
operation.
2. The Rev. A and later chassis is required for 1:1 or 1:N operation. It supports Tx Only, Rx
Only, and Duplex operation
The European EMC Directive (EN55022, EN50082-1) requires using properly shielded cables for
DATA I/O. These cables are double-shielded from end-to-end, ensuring a continuous ground shield.

Table 3-1. Modem Rear Panel Connectors

Note 1 )
)
Note 2
)
Note 1
)
Note 2
Connector Type
CDM-710 (70/140 MHz band):
BNC female
CDM-710L (L-Band):
Type 'N' female
CDM-710 (70/140 MHz band):
BNC female
CDM-710L (L-Band):
Type 'N' female
RJ-45 Female
RJ-45 Female
9-pin Type 'D' female
15-pin Type 'D' male
9-pin Type 'D' male
SMA Female
BNC female
IEC
Terminal block
#10-32 stud
3–2
Revision 11
MN/CDM710.IOM
Function
IF Output
IF Input
10/100 BaseT Remote Interface
Private communications link
Asynchronous Engineering
Channel
Form C Alarms (relay closures)
Serial Remote Interface (RS232/485)
External Reference Input
External Reference Input
Chassis prime power input
Chassis prime power input
Common Chassis Ground
