CDM-710 Broadcast Satellite Modem
Front Panel Operation
(CONFIG: Intfc2 Gigabit Ethernet) Ingress
To enter the Destination UDP port for ingress streams, first use the ◄ ► arrow keys
to select the desired digit to edit, then use the ▲ ▼ arrow keys to change the value of
that digit. Press
(CONFIG: Intfc2 Gigabit Ethernet) Ingress
Intfc2 Multicast Mode
Single
Select Single or Dual using the ◄ ► arrow keys, then press
Select Single if one IP connection carrying an MPEG-2 transport stream is present, or if
automatic redundancy switching is disabled.
Select Dual for redundancy operation with dual IP connections, each transporting an
MPEG-2 transport stream, and automatic switching between the two streams is performed.
(CONFIG: Intfc2 Gigabit Ethernet) Ingress
Intfc2 Primary Stream
1
Select 1 (Single) or 2 (Redundancy) Mode using the ◄ ► arrow keys, then press
In Single mode, this assigns which (of up to two) streams is processed. In Redundancy
mode, this identifies which of two streams are initially processed before any redundancy
switch takes place.
(CONFIG: Intfc2 Gigabit Ethernet) Ingress
Intfc2 Redundancy
Revertive
Select Revertive or Non-Revertive using the ◄ ► arrow keys, then press
In Revertive Redundancy mode, either stream can be processed in the event of the
failure of the other stream.
In Non-revertive Redundancy mode, a switch from the primary stream to the
secondary stream can occur, but a switch from the secondary stream to the primary
stream will not occur in the event of a failure of the secondary stream. In this latter
case, user intervention is required.
Intfc2 UDP Port
05060
when done.
ENTER
Dual
2
Non-Revertive
Str
Str
Str
Str
5–32
Revision 11
MN/CDM710.IOM
IP Port
Mode
.
ENTER
Pri
ENTER
Red
.
ENTER
.
