CDM-710 Broadcast Satellite Modem
Appendix A
Command
Arguments for
Parameter
(Instruction
Command or
Type
Code and
Response to
Qualifier)
Query
Transmit &
TRC=
69 bytes
Receive
Configuration
Description of Arguments
Command or Query.
Global configuration, in the form:
aaa.aaaabcc.ccccccdefghhhhhhiii.ijkllll.llllmnn.nnnnnnopqrsssssstuvv, where:
aaaa.aaaa = Tx Frequency (in MHz)
b = Tx Mode
cc.cccccc = Tx Symbol Rate
d = Tx FEC Type
e = Tx Modulation type
f = Tx FEC Rate
g = Tx Spectrum Inversion
hhhhhh = Tx Gold Code Sequence
iii.i = Tx Power Level
j = Tx Carrier State
k = Tx Alpha Roll-off
llll.llll = Rx Frequency (in MHz)
m = Rx Mode
nn.nnnnnn = Rx Symbol Rate
o = Rx FEC Type
p = Rx Modulation type
q = Rx FEC Rate
x = spare
ssssss = Rx Gold Code Sequence
t = Rx Alpha Roll-off
u = Unit test Mode
vv = Unit Alarm Mask
same as TFQ
same as TMM
same as TSR
same as TFT **
same as TMD
same as TCR
same as TSI
same as TGS
same as TPL
same as TXO
same as TAR
same as RFQ
same as RMM
same as RSR
same as RFT **
same as RMD
same as RCR
same as RGS
same as RAR
same as TST**
same as MSK
** Read-only
A–32
MN/CDM710.IOM
Query
Response to
(Instruction
Response to Query
Command
Code and
Qualifier)
TRC=
TRC?
TRC=
TRC?
aaaa.aaaabcc.ccccccdefghhh
TRC*
hhhiii.ijkllll.llllmnn.nnnnnnopqx
TRC#
sssssstuvv
Returns current transmit and
receive configuration.
Notes:
1. Unit returns 'x's for Rx
parameters if unit is modulator
only.
2. Unit returns 'x's for Tx
parameters if unit is
demodulator only.
3. If Rx is in DVB-S2 mode,
the Rx Modulation Type and
Rx FEC Rate is ignored
because these are
automatically detected.
Revision 11
