Common Private MIBs

The CDM-710 SNMP agent also implements four private MIBs. The CDM-710 Common MIB
holds all unit parameters not associated with Modulator, Demodulator, FEC, or Interface boards.
For detailed OID information please refer to the actual MIB file.
Name
System Information Group
Remote Serial Group
Remote Ethernet Group
Ethernet SNMP Group
Interface FEC Group
Modem Reference Group
Monitor Group
Test Group
Save/Load Group
Utilities Group
Firmware Group
6.3.1.2

Modulator Private MIB

The CDM-710 Modem MIB holds all unit parameters associated with the Modulator. For
detailed OID information please refer to the actual MIB file.
6.3.1.3

ASI Private MIB

The CDM-710 ASI MIB holds all unit parameters associated with the ASI interface board. For
detailed OID information please refer to the actual MIB file.
6.3.1.4

Redundancy-Switch Private MIB

The CDM-710 Modem MIB holds all unit parameters associated with 1:1 Redundancy
operations. For detailed OID information please refer to the actual MIB file.
6.3.1.5

Gigabit Ethernet MIB

The CDM-710 Modem MIB holds all unit parameters associated with the Gigabit Ethernet
Interface. For detailed information, refer to the actual MIB file.
Description
This group provides Serial Number and Model Number information as well as an interface
table that defines the exact hardware configuration of the unit.
This group provides the parameters of the modem's legacy Serial interface. This includes
the Local/Remote State, Physical Interface (RS-232 or RS-485), Address and baud rate
selections. In addition, this group provides address selection for the 1:1 redundancy
controller.
This group provides the parameters of the modem's Ethernet interface. This includes the IP
Address and Mask, IP Gateway, and MAC Address.
This group provides the parameters necessary to configure and operate the SNMP interface.
This includes the System Name, Administrator and Location as well as the Community
Strings.
This group provides information regarding unit's two FEC Slots and the capabilities of the
cards loaded in those slots.
This group provides the parameters for selection of the modem's frequency reference.
This group provides access to the units current Alarm/Fault Status as well as a table to
access the Stored Alarms/Events.
This group provides access to the units test modes.
This group provides control of the unit's configuration Store and Load capabilities.
This group provides access to the unit's Real-Time clock (Time and Date), Internal
Reference Adjustment, Circuit ID, and Front Panel Display Brightness Control.
This group provides a table of firmware numbers, Revision Numbers, and Release Dates for
all the software/firmware within the unit.
