CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Initialize Events
IEP= None
Pointer
Boot Image
IMG= 1 byte
IP Address
IPA= 18 bytes
Gateway
IPG= 15 bytes
Address
Interface Type
N/A 2 bytes
Rx Link Margin
N/A 4 bytes
Local/Remote
LRS= 1 byte
Status
Unit MAC
N/A 12 bytes
Address
Description of Arguments
Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the
stored events log.
Command only.
Boot image selection, where n is the image number in the form n, where:
1=Image #1
2=Image #2
Example: IMG=1 (Image #1 selected for booting.)
Command or Query.
Used to set the IP address and network prefix for the 10/100 BaseTx Ethernet
management port, in the form xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx is the IP address
yy is the network prefix (00..31)
Example: IPA=010.006.030.001.24
Command or Query.
Used to set the Gateway IP addess for the 10/100 Base Tx Ethernet
management port, in the form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx is the IP address
Example: IPG = 010.006.030.001
Query only.
Interface Type in the form sx, where:
s=Defines which interface slot (1 or 2)
x=Defines the interface type, where:
0=ASI
1=Gigabit Ethernet
2=HSSI
Example: ITF?1
Query only.
Unit returns the value of the Link Margin. Returns 00.0 if demod is unlocked.
Example: LNK=12.3
Command or Query.
Local/Remote status in the form x, where:
0=Local
1=Serial
2=Reserved
3=Ethernet
4=Serial+Ethernet
Example: LRS=1 (Serial Remote selected)
Query only.
MAC address of the unit, reported in hexadecimal.
Example: MAC=0006B000D2A7 (The MAC address of the unit is
00:06:B0:00:D2:A7 )
A–45
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
IEP= N/A N/A
IEP?
IEP*
IEP#
IMG= IMG? IMG=n
IMG?
IMG*
IMG#
IPA= IPA? IPA= xxx.xxx.xxx.xxx.yy
IPA?
IPA*
IPA#
IPG= IPG? IPG = xxx.xxx.xxx.xxx
IPG?
IPG*
IPG#
ITF? ITF?s ITF=sx
ITF*
ITF#
LNK? LNK? LNK=xxxx
LNK*
LNK#
LRS= LRS? LRS=x
LRS?
LRS*
LRS#
MAC? MAC? MAC=AABBCCDDEEFF
MAC*
MAC#
Revision 11
