CDM-710 Broadcast Satellite Modem
Front Panel Operation
5.3.3.2

(Test:) TestPatterns

The availability of test patterns depends on the installed, enabled interface. The example for the
menu that is displayed if the CDI-40 ASI interface is installed in Slot 1, or the CDI-70 Gigabit
Ethernet Interface is installed in Slot 2, is as follows:
Test Pattern Subst:
Off 2047
Select Off, 2047, or 2^23-1 using the
If, however, the CDI-60 HSSI Interface is installed and enabled in Slot 1, the following message
displays:
Test Pattern Subst:
N/A on HSSI Intfc
Press or
ENTER

5.3.4 SELECT: Info

INFO: Rem
Intfc1
Select a submenu from the Info: menu branch – Rem, Tx, Rx, Intfc1, or Intfc2 – using the
arrow keys, then press
Note: INFO screens provide read-only information on the current configuration of the modem
without risking inadvertent changes. The user may only view, but not edit, an Info screen.
5.3.4.1

(INFO:) Rem

Remote M&C: 100BaseTx
IP Addr: 192.168.001.006
This display provides the status, as applicable, of the Remote Monitor & Control configuration.
2^23-1
to return to the previous menu.
CLEAR
Tx Rx
(
.
ENTER
arrow keys, then press
E)
5–46
Revision 11
MN/CDM710.IOM
.
ENTER
