CDM-710 Broadcast Satellite Modem
Appendix A
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier) Query
Description of Arguments
c=Rx Traffic Status
0=No faults
1=+1.5V Demod Power Supply Unit (Demodulator Card)
2=FPGA Load (Demodulator Card)
3=Demod Unlocked
4=DSNG Sync Error
5=FPGA Temperature (Demodulator Card)
6=Reserved
7=AGC Level Out of Range
8=Eb/No Limit Exceeded
9=Demodulator Synth 1 PLL
A=Demodulator Synth 2 PLL
B= SERDES Demod to Framer
C= SERDES Framer to FEC1
D= SERDES Framer to FEC2
E=Reserved
F= MPEG transport stream error.
G=ASI Rx PLL Empty (Interface 1)
H=ASI Rx PLL Full (Interface 1)
I=ASI Rx PLL Lower Limit Reached (Interface 1)
J=ASI Rx PLL Upper Limit Reached (Interface 1)
K=Reserved
L=Reserved
M=Reserved
N=Reserved
O=Reserved
P=ASI Rx SERDES Error (Interface 1)
Q=ASI Rx SERDES DCM Unlocked (Interface 1)
R= Reserved
S= Reserved
T=HSSI Rx Buffer Underrun (Interface 1)
U=HSSI Rx Buffer Overflow (Interface 1)
V=Reserved
W=Reserved
X=Framer SERDES Rx Fault (Interface 1)
Y=Framer SERDES Rx Fault (Interface 2)
Z=Reserved
[=Reserved
d=New Faults
0=No new faults
1=New faults since last check
A–42
MN/CDM710.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
Revision 11
