CDM-710 Broadcast Satellite Modem
Front Panel Operation

(Firmware:) Info

Firmware Info: Bootrom

Image#1
To view information on the Bootrom and the two images, select Bootrom, Image#1, or Image#2
using the
(Firmware:) Info
Bootrom:
CDM710_Boot
This screen provides information on the installed Bootrom firmware. The release date is provided
on the top line in DAY/MONTH/YEAR format; the bottom line identifies the installed Firmware
by its release name/number and its version number (Note: The firmware information shown in the
preceding example is representative and may differ from what is identified for the unit in use).
Press or
ENTER
(Firmware:) Info
Image#X: Bulk
FEC Mod
Where X indicates the selected Image: On the next page, Table 5-5 provides an overall summary
of examples for each available firmware info screen. As shown, the first column for either Image
provides the available selection; the second column provides an example of the information
provided for that selection.
Note: The information in this table is representative; the numbers, revision letters, versions, and
release dates for the firmware listed in this table are subject to change.

(Firmware:) Select

Current Active Image: #2
Next Reboot Image:
The top line shows the active image. To select the active software image, on the second line, select
the desired image using the
To make the selected image the active choice, power cycle the modem to reboot using the selected
software image.
Image#2
arrow keys, then press
ENTER
Bootrom
07/17/06
to return to the previous menu.
CLEAR
Image#1, Image#1
App Framer
Demod Interfaces
#1 #2
arrow keys, then press
to continue.
1.1.1
ENTER
5–52
MN/CDM710.IOM
.
Revision 11
