CDM-710 Broadcast Satellite Modem
FAST Activation Procedure
C.2.3

Purchase FAST Access Code

Contact a Comtech EF Data sales representative during normal business hours to order features.
You will be asked to provide the modem Serial Number. Comtech EF Data Customer Support
will verify the order and provide an invoice, instructions, and a 20-character FAST access
(configuration) code.
C.2.4

Enter FAST Access Code

Enter the FAST access code as follows:
a) Press [CLEAR] to return to the
b) Select
c) Select
d) Enter the 20-character FAST code carefully. Use the ◄ ► arrow keys to move the cursor
to each character, then use the ▲ ▼ arrow keys to edit that character:
e) Press ENTER when done. The modem responds with "Configured Successfully"
if the new FAST option is accepted:
Press [ENTER] or [CLEAR] as directed. The modem will then reset to its default
configuration.
20 Tx <=37.5 MS
21 Tx <=45.0 MS
22 Rx <=15.0 MS
23 Rx <=22.5 MS
24 Rx <=30.0 MS
25 Rx <=37.5 MS
26
Rx <=45.0 MS
27
Tx DVB-S1
28
Tx DVB-S2
29
Tx DVB-DSNG
30 Rx DVB-S1
31 Rx DVB-S2
32 Rx DVB-DSNG
FAST: Cnfg View
MainBoard S/N: 333333333
, then press [ENTER]:
Cnfg
FAST Configuration:
Edit Code Demo Mode
then press [ENTER].
Edit Code,
Edit 20 digit FAST Code:
00000000000000000000 ENT
Configured Successfully
(ENTER or CLEAR)
menu:
UTILITY FAST
C–3
Revision 11
MN/CDM710G.IOM
