Technical Specifications
007-4653-001
Table 3-3 lists the technical specifications of the Cx-brick.
Table 3-3 Cx-brick Technical Specifications
Characteristic Specification
Height 6.8 in. (172.72 mm)
Width 17.5 in. (444.5 mm)
Depth 27.5 in. (698.5 mm)
Weight 70 lb (31.75 kg)
DC input power +48 VDC (~1100 Watts DC)
Table 3-4 lists the specifications of the Cx-brick ports.
Cx-brick Port Specifications
Table 3-4
Port Quantity
NUMAlink 3 4
XIO 4
Specification
1.6 GB/s each direction
1.2 GB/s each direction

Technical Specifications

63
