7: R-brick
Technical Specifications
102
Table 7-1 lists the technical specifications of the R-brick.
Table 7-1 R-brick Technical Specifications
Characteristic Specification
Height 3.3 in. (83.82 mm)
Width 17.38 in. (441.45 mm)
Depth 27.5 in. (698.50 mm)
Weight 20 lb (9.1 kg)
Input power 48 VDC (~ 60 W)
Table 7-2 lists the specifications of the R-brick ports.
Table 7-2 R-brick Port Specifications
Port Quantity Peak Transfer Rate
link 8
L1 1 12 Mbits/s
1.6 GB/s each direction
007-4653-001
