Targeting All Bricks Within Rack

130
To select all bricks within a rack, see Figure 8-15 and follow these steps:
1. Press the Rack/Slot button.
2. Press the button for the rack (for example, Figure 8-15 shows rack 001 selected).
Rack/Slot Partition
ALL << >>
CLR
001 002 003 004
101 102
New DEST: r 1 s *
Apply
Target Selection Window
Figure 8-15
The new destination is reflected in the destination field near the bottom of the display
window. For example, Figure 8-15 shows all slots in rack 001 (r1 s *) as the destination.
Once you have selected the rack, press the Apply button to set the new destinations. The
home window will then reappear. The new destinations are reflected in the destination
field across the bottom of the home window display.
