ICE X D-Rack Technical Specifications

007-5806-004
Table 4-1 lists the technical specifications of the SGI ICE X series D-Rack.
Table 4-1 Tall SGI ICE X D-Rack Technical Specifications
Characteristic
Height
Width
Depth
Weight (full)
Shipping weight (max)
Voltage range
Nominal
Tolerance range
Frequency
Nominal
Tolerance range
Phase required
Power requirements (max) 34.58 kVA (33.89 kW)
Hold time
Power cable
Important: The D-rack's optional water-cooled door panels only provide cooling for the bottom
42U of the rack. If the top of the rack is "expanded" 2U, 4U, or 6U, to accommodate optional
system components, the space in the extended zone is not water cooled.
See "System-level Specifications" in Appendix A for a more complete listing of SGI ICE X
system operating specifications and environmental requirements.
Specification
79.5 in. (201.9 cm) 82.25 in (208.9 cm) with 2U top
24 in. (61 cm) - optionally expandable
49.5 in. (125.7 cm) - air cooled; 50.75 in. (128.9 cm)
- water cooled
~2,500 lbs. (1,136 kg) approximate (water cooled)
~2,970 lbs. (1,350 kg) approximate maximum
North America/International
200-240 VAC /230 VAC
180-264 VAC
North America/International
60 Hz /50 Hz
47-63 Hz
3-phase (optional single-phase available in I/O rack)
16 ms
12 ft. (3.66 m) pluggable cords
ICE X D-Rack Technical Specifications
61
